Dimensions: 250.8 mm x 152.0 mm x 15.0 mm / 9.87 x 5.98 x 0.59 in. ( for standard version )
Weight: 700 g / 24.7 oz. ( for standard version )
Display: 8” IPS LTPS 1920 x 1200
Touch Panel: Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
Power: Main battery: Li-ion, rechargeable, 8000 mAh, Standby: over 500 hours, Continuous use: over 10 hours ( depending on user environment ), Charging time: 5-7 hours ( with standard AC adaptor and USB cable )
Expansion Slot: 1 slot for SIM card, 1 slot for SIM / TF card, Optional dual PSAM card slots
Interfaces: USB 3.0 Type-C, OTG
Audio: Speaker, microphone
Keypad: 1 front key, 1 volume key, 1 power key, direction key (optional)
Sensors: Gravity sensor, gyroscope, accelerometer sensor
Operating Temp.: -20°C to 50°C
Storage Temp.: -40°C to 70°C
Humidity: 5% RH – 95% RH non condensing
Drop Specification: Multiple 1.5 m / 4.9 ft. drops ( at least 20 times ) to the concrete across the operating temperature range
Tumble Specification: 500 x 0.5 m / 1.64 ft. falls at room temperature
Sealing: IP65 per IEC sealing specifications
ESD: ±15 KV air discharge, ±8 KV conductive discharge
Operating System: Android 9.0; GMS, Android Enterprise, Zero-Touch,FOTA, Soti MobiControl, SafeUEM supported
SDK: Chainway Software Development Kit
Language: Java
Tool: Eclipse / Android Studio
CPU: Qualcomm 1.8 GHz Octa-core
RAM+ROM: 3 GB + 32 GB
Expansion: Supports up to 128 GB Micro SD card
WLAN: IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
WWAN: (above ground only)
2G: B3/B5/B8
3G: CDMA EVDO: BC0
3G: TD-SCDMA: B34/B39
3G: WCDMA: B1/B5/B8
4G: TDD-LTE: B38/B39/B40/B41
4G: FDD-LTE: B1/B3/B5/B7/B8/B20
WWAN (America)
3G: B2/B4/B5
4G: B2/B4/B5/B7/B12/B13/B17/B28b
WWAN (Others)
Depending on the country’s ISP
Bluetooth: Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
GNSS: GPS/AGPS, GLONASS, BeiDou, internal antenna
Camera: 13MP Autofocus with flash
Front Camera: 8 MP
Frequency: 13.56MHz
Protocol: ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips: M1 card ( S50, S70 ), CPU card, NFC tags, etc.
Range: 2-4 cm
Wavelength: 940 nm
Frequency: 38 kHz
Range: > 4 m
Protocol: DLT_645-2007, DLT_645-1997
Note: * This function currently only has an interface reserved.
Rate: < 150 ms
Range: 20-40 cm
FAR: 1/10000000
Note: Protocol：ISO/IEC 19794-6，GB/T 20979-2007
Note2: * This function currently only has an interface reserved.
* Front Iris
Fingerprint
Sensor: TCS1/TCS2 Capacitive; Optical Morpho CBM-E3
Sensing Area (mm): 12.8 x 18; 10.4 x 14.4; 14 x 22
Resolution (dpi): 508 dpi, 8-bit greylevel; 500 dpi, 256 greylevel
Certifications: FIPS 201, STQC; FIPS PIV IQS / ISO 19794-4, MINEX & FIPS 201 complaint, STQC
Format Extraction: ISO 19794, WSQ, ANSI 378, JPEG2000; ISO 19794-2/4, WSQ, ANSI 378, etc.
Security: AES, DES key encryption of the host communication channel; FIPS 140-2 level 2, multiple security methods available, including image and templates encryption, template signature, secure tunneling, etc.
Fake Finger Detection: Support by SDK; Latex, Gelatin, Plasticine, Kapton, Transparent Film, Silicone, Rubber, Play-doh, Graphite Or Paper
Note: * This function is optional
PSAM
Protocol: ISO7816
Slots: 2 PSAM card slots
Note: * This function is optional
UHF RFID
Engine: CM2000-1 module based on Impinj Indy R2000
Frequency: 865-868 MHz / 920-925 MHz / 902-928 MHz
Protocol: EPC C1 GEN2 / ISO18000-6C
Antenna: Circular polarization ( default UHF, 3dBi ; UHF with pistol grip, 4dBi )
Power: 1W ( 30dBm, +5dBm to +30dBm adjustable ), 2W Optional ( 33dBm, for Lati America, etc. )
R/W ranges: ＞25 m (indoors); ＞15 m (open outdoors, Impinj MR6 tag)
Reading rates (circular polarization): ＞200 tags/s
Note: * This function is optional
Note2: * Ranges and rates depend on tags and environment
Barcode Scanning
Scan engine: Zebra SE4710 ( standard ) , Zebra SE4850 ( optional )
1D Symbologies: UPC/EAN, Code128, Code39, Code93, Code11, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, MSI, RSS, etc.
2D Symbologies: PDF417, MicroPDF417, Composite, RSS, TLC- 39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
Note: * This function is optional
HF RFID
Frequency: 13.56 MHz
Note: * This function is optional
Note2: * HF RFID is alternative to NFC
